Inserting Rewrite rule in Release Config

by Abhith RajanAugust 12, 2017 · 3 min read · Last Updated:
Share this

My Web.config’s system.webServer section initially looked like this,

1<system.webServer>
2....
3<!--If you wish to use IIS rewrite rules,
4see the documentation here:https://our.umbraco.org/documentation/Reference/Routing/IISRewriteRules-->
5 <!--<rewrite>
6 <rules></rules>
7 </rewrite> -->
8</system.webServer>

And my Web.Release.config looked like this,

1<?xml version="1.0" encoding="utf-8"?>
2
3<!-- For more information on using web.config transformation visit https://go.microsoft.com/fwlink/?LinkId=125889 -->
4
5<configuration xmlns:xdt="http://schemas.microsoft.com/XML-Document-Transform">
6 <!--
7 In the example below, the "SetAttributes" transform will change the value of
8 "connectionString" to use "ReleaseSQLServer" only when the "Match" locator
9 finds an attribute "name" that has a value of "MyDB".
10
11 <connectionStrings>
12 <add name="MyDB"
13 connectionString="Data Source=ReleaseSQLServer;Initial Catalog=MyReleaseDB;Integrated Security=True"
14 xdt:Transform="SetAttributes" xdt:Locator="Match(name)"/>
15 </connectionStrings>
16 -->
17 <system.web>
18 <compilation xdt:Transform="RemoveAttributes(debug)" />
19 <!--
20 In the example below, the "Replace" transform will replace the entire
21 <customErrors> section of your web.config file.
22 Note that because there is only one customErrors section under the
23 <system.web> node, there is no need to use the "xdt:Locator" attribute.
24
25 <customErrors defaultRedirect="GenericError.htm"
26 mode="RemoteOnly" xdt:Transform="Replace">
27 <error statusCode="500" redirect="InternalError.htm"/>
28 </customErrors>
29 -->
30 </system.web>
31</configuration>

Now I have to add a rule which redirects all non-www requests to www route. I accomplished the same by modifying the Web.config to,

1<system.webServer>
2....
3<!--If you wish to use IIS rewrite rules,
4see the documentation here:https://our.umbraco.org/documentation/Reference/Routing/IISRewriteRules-->
5 <rewrite>
6 <rules></rules>
7 </rewrite>
8</system.webServer>

And my Web.Release.Config to,

1<?xml version="1.0" encoding="utf-8"?>
2
3<!-- For more information on using web.config transformation visit https://go.microsoft.com/fwlink/?LinkId=125889 -->
4
5<configuration xmlns:xdt="http://schemas.microsoft.com/XML-Document-Transform">
6 <!--
7 In the example below, the "SetAttributes" transform will change the value of
8 "connectionString" to use "ReleaseSQLServer" only when the "Match" locator
9 finds an attribute "name" that has a value of "MyDB".
10
11 <connectionStrings>
12 <add name="MyDB"
13 connectionString="Data Source=ReleaseSQLServer;Initial Catalog=MyReleaseDB;Integrated Security=True"
14 xdt:Transform="SetAttributes" xdt:Locator="Match(name)" />
15 </connectionStrings>
16 -->
17 <system.web>
18 <compilation xdt:Transform="RemoveAttributes(debug)" />
19 <!--
20 In the example below, the "Replace" transform will replace the entire
21 <customErrors> section of your web.config file.
22 Note that because there is only one customErrors section under the
23 <system.web> node, there is no need to use the "xdt:Locator" attribute.
24
25 <customErrors defaultRedirect="GenericError.htm"
26 mode="RemoteOnly" xdt:Transform="Replace">
27 <error statusCode="500" redirect="InternalError.htm" />
28 </customErrors>
29 -->
30 </system.web>
31 <system.webServer>
32 <rewrite>
33 <rules>
34 <clear />
35 <rule name="Redirect Non WWW" stopProcessing="true" xdt:Transform="Insert">
36 <match url=".*" />
37 <conditions>
38 <add input="{HTTP_HOST}" pattern="^(?!www)(.*)$" />
39 </conditions>
40 <action type="Redirect" redirectType="Permanent" url="https://www.{C:1}/{R:0}" />
41 </rule>
42 </rules>
43 </rewrite>
44 </system.webServer>
45</configuration>

Noticed the xdt:Transform=“Insert” in the line,

1<rule name="Redirect Non WWW" stopProcessing="true" xdt:Transform="Insert">

Which will add the rule to the Web.config automatically during publishing.

This article is part of my daily google series. And this is the very first post in this category.
